DIN 25201 Stainless Steel Wedge Lock Washer
Stainless Steel Wedge Lock Washer according to DIN 25201 standard, material by A2/A4 Stainless steel, M3-M100 available in stock from China Lock Washer Manufacturer
 |
 |
Stainless Steel Wedge Lock Washer according to DIN 25201 standard
Made of Stainless steel SUS304 or SUS316
Size: M4-M100 ( NL4 – NL100 )
| Size (Metric) |
Part number | d (mm) |
D (mm) |
T (mm) |
Weight (kg/100Pair) |
| M3 | NL3ss | 3.4 | 7 | 2.2 | 0.04 |
| M3,5 | NL3,5ss | 3.9 | 7.6 | 2.2 | 0.04 |
| M3,5 | NL3,5spss | 3.9 | 9 | 2.2 | 0.07 |
| M4 | NL4ss | 4.4 | 7.6 | 2.2 | 0.04 |
| M4 | NL4spss | 4.4 | 9 | 2.2 | 0.07 |
| M5 | NL5ss | 5.4 | 9 | 2.2 | 0.06 |
| M5 | NL5spss | 5.4 | 10.8 | 2.2 | 0.11 |
| M6 | NL6ss | 6.5 | 10.8 | 2.2 | 0.09 |
| M6 | NL6spss | 6.5 | 13.5 | 2 | 0.16 |
| 1/4” | NL1/4”ss | 7.2 | 11.5 | 2.2 | 0.09 |
| 1/4” | NL1/4”spss | 7.2 | 13.5 | 2.2 | 0.15 |
| M8 | NL8ss | 8.7 | 13.5 | 2 | 0.12 |
| M8 | NL8spss | 8.7 | 16.6 | 2 | 0.23 |
| 3/8” | NL3/8”ss | 10.3 | 16.6 | 2 | 0.19 |
| 3/8” | NL3/8”spss | 10.3 | 21 | 2 | 0.38 |
| M10 | NL10ss | 10.7 | 16.6 | 2 | 0.18 |
| M10 | NL10spss | 10.7 | 21 | 2 | 0.37 |
| M12 | NL12ss | 13 | 19.5 | 2 | 0.23 |
| M12 | NL12spss | 13 | 25.4 | 3 | 0.82 |
| 1/2” | NL1/2”ss | 13.5 | 19.5 | 2 | 0.22 |
| 1/2” | NL1/2”spss | 13.5 | 25.4 | 3.2 | 0.8 |
| M14 | NL14ss | 15.2 | 23 | 3 | 0.49 |
| M14 | NL14spss | 15.2 | 30.7 | 3.2 | 1.31 |
| M16 | NL16ss | 17 | 25.4 | 3 | 0.59 |
| M16 | NL16spss | 17 | 30.7 | 3.2 | 1.13 |
| M18 | NL18ss | 19.5 | 29 | 3.2 | 0.8 |
| M18 | NL18spss | 19.5 | 34.5 | 3.2 | 1.56 |
| 3/4” | NL3/4”ss | 20 | 30.7 | 3.2 | 0.96 |
| 3/4” | NL3/4”spss | 20 | 39 | 3.2 | 2.1 |
| M20 | NL20ss | 21.4 | 30.7 | 3 | 0.82 |
| M20 | NL20spss | 21.4 | 39 | 3.2 | 2.06 |
| M22 | NL22ss | 23.4 | 34.5 | 3.2 | 1.23 |
| M22 | NL22spss | 23.4 | 42 | 3.2 | 2.23 |
| M24 | NL24ss | 25.3 | 39 | 3.2 | 1.59 |
| M24 | NL24spss | 25.3 | 48.5 | 4.5 | 4.47 |
| 1” | NL1”ss | 27.9 | 39 | 3.2 | 1.42 |
| 1” | NL1”spss | 27.9 | 48.5 | 3.2 | 2.79 |
| M27 | NL27ss | 28.4 | 42 | 6.8 | 3.45 |
| M27 | NL27spss | 28.4 | 48.5 | 6.8 | 5.34 |
| M30 | NL30ss | 31.4 | 47 | 6.8 | 4.49 |
| M30 | NL30spss | 31.4 | 58.5 | 6.8 | 9.18 |
| M33 | NL33ss | 34.4 | 48.5 | 6.8 | 4.28 |
| M36 | NL36ss | 37.4 | 55 | 6.8 | 5.96 |
| M39 | NL39ss | 40.4 | 58.5 | 6.8 | 6.74 |
| M42 | NL42ss | 43.2 | 63 | 6.8 | 7.5 |
| M45 | NL45ss | 46.2 | 70 | 6.8 | 10.2 |
| M48 | NL48ss | 49.6 | 75 | 6.8 | 12 |
| M52 | NL52ss | 53.6 | 80 | 9 | 18.04 |
| M56 | NL56ss | 59.1 | 85 | 9 | 21.3 |
| M60 | NL60ss | 63.1 | 90 | 9 | 23.5 |
| M64 | NL64ss | 67.1 | 95 | 9 | 25.8 |
| M68 | NL68ss | 71.1 | 100 | 9 | 28.2 |
| M72 | NL72ss | 75.1 | 105 | 9 | 30.7 |
| M76 | NL76ss | 79.1 | 110 | 9 | 33.3 |
| M80 | NL80ss | 83.1 | 115 | 9 | 36 |
